P96 - Fleet-Lift Two-Hole Anchor

Accessories

Dayton
The Dayton Superior P96 Fleet-Lift Two-Hole Anchor is always used in conjunction with the Dayton Superior P98T Tension Bar. The anchor has a bottom hole especially designed to accept the tension bar. Place the P98T Tension Bar through the bottom hole in such a manner that the ends of the tension bar are pointing downward. Fasten the tension bar tight against the bottom side of the hole. The tension bar distributes the tension forces, developed from the lifting process, deep into the precast concrete. This allows the lifting of very thin and/or low concrete compressive strength panels. Do not use the P96 Two-Hole Anchor in the following situations: 1) Without a correct size and located tension bar. 2) In the edge of thin panels where shear loads will be applied to the anchor.

Pricing Information/Unit Sizes

Product Code Packaging
FL190 TWO-HOLE ANCHOR P92H 2 TON 2.75" PLAIN
FL122 TWO-HOLE ANCHOR P92H 2 TON 4.00" PLAIN
FL124 TWO-HOLE ANCHOR P92H 4 TON 5.50" PLAIN
FL125 TWO-HOLE ANCHOR P92H 8 TON 7.00" PLAIN
Specific customer pricing may be available in Dayton Access. Minimum standard packaging sizes may apply.
