B29 - Plastic Cones for Coil Ties

Accessories | Wall Forming Accessories

Dayton
Dayton Superior B29 Loose Plastic Cones are used with B1 and B2 Coil Ties. They are placed on the coil bolts after the coil bolts have been inserted through the form face but prior to threading the bolt into the coil tie. The large end of the cone provides sufficient bearing surface to prevent crushing of the plywood around the bolt hole. B29 plastic cones are removed from the concrete with a B15 Cone Removal Wrench and can be reused.

Pricing Information/Unit Sizes

Product Code Packaging
35121 LOOSE CONE PLASTIC 1/2" X 1" SETBACK
35122 LOOSE CONE PLASTIC 1/2" X 1-1/2" SETBACK
35123 LOOSE CONE PLASTIC 1/2" X 2" SETBACK
35125 LOOSE CONE PLASTIC 3/4" X 1" SETBACK
35126 LOOSE CONE PLASTIC 3/4" X 1-1/2" SETBACK
35127 LOOSE CONE PLASTIC 3/4" X 2" SETBACK
35128 LOOSE CONE PLASTIC 1" X 2-1/2" SETBACK
35129 LOOSE CONE PLASTIC 1-1/4" X 2-1/2" SETBACK
Specific customer pricing may be available in Dayton Access. Minimum standard packaging sizes may apply.
